E100:
ESWIN Computing E100 32-bit general-purpose microprocessor is an extremely small 32-bit RISC-V embedded CPU IP product with ultra-low power consumption. kết quả bóng đá trực tuyến hôm nay

E100, the smallest processor in the entire series, features an NAND2V1 equivalent gate count of less than 10,000. E100 supports machine mode, standard RISC-V Debug and RISC-V CLNT, and includes optional extensions including RV32E integer instructions, hardware multiply & divide instructions, and Zc V1.0 compressed instructions. Trang cá cược It is suitable for area-sensitive IoT devices and microcontrollers, such as smart cards, smart grids, and wireless sensor networks.
E100
Features
Features Description
ISA RISC-V 32-bit(E/I)(M)(C/Zc)
Modes Machine-mode
Pipeline 2-stage pipeline
Interrupt Supports up to 16 interrupt requests Trang cá cược
Debug Debug module: supports TAG/cJTAG
Bus Interface System Port: 32-bit AHB-Lite master interface
Misaligned Access Optional
CoreMark (CoreMarks/MHz) 2.11
Dhrystone-Legal (DMIPS/MHz) 0.79
