S516:
ESWIN Computing S516 64-bit AI acceleration processor is a high energy-efficient RISC-V application-level CPU IP product that meets the RVA23-Profile.
ti le cuoc
Supports Advanced Interrupt Architecture (AIA).
The applicable scenarios include edge computing, smart TVs, set-top boxes, computers, mobile devices, and other intelligent computing domains.
Supports Advanced Interrupt Architecture (AIA).
The applicable scenarios include edge computing, smart TVs, set-top boxes, computers, mobile devices, and other intelligent computing domains.
Features
| Features | Description | ||||
| ISA | RVA23+Vector Crypto | ||||
| Multi-core | Supports up to 8 cores per cluster | ||||
| Modes | Machine-mode, Hypervisor-mode, Supervisor-mode, User-mode | ||||
| Security | Supports ESWIN TEE solution, with up to 64 PMP regions | ||||
| Crypto | Supports optional scalar, vector hardware encryption and decryption module | ||||
| Vector | Supports RVV1. keo ca cuoc 0, with configurable widths (128-bit, 256-bit, 512-bit, or 1024-bit) | ||||
| Virtualization | Virtualization - IOMMU +AIA | ||||
| Pipeline | 8-stage superscalar in-order pipeline, 2-way decode | ||||
| Branch Predictor | L0_BTB, IJTB, NN-Predictor, RAS, Loop Buffer | ||||
| Prefetch | Supports instruction prefetch, data prefetch | ||||
| Architecture features | Supports instruction fusion, write streaming mode, partial out-of-order execution ti le cuoc | ||||
| L1 I$ | Size is configurable from 8KB to 64KB, ECC optional | ||||
| L1 D$ | Size is configurable from 8KB to 64KB, ECC optional | ||||
| Cluster LLC | Size is configurable from 256KB to 4MB, ECC optional | ||||
| MMU | SV39/SV48, ITLB, DTLB Supports hardware self-modifying PTE (Page Table Entry) | ||||
| Interrupt | APLIC（AIA+PLIC） | ||||
| Debug |
Debug module: supports JTAG
Trace module: supports RISC-V standard E-Trace/ N-Trace |
||||
| Bus Interface |
1.Memory Port: 128–bit AXI master interface
2.Peripheral Port: 64-bit AXI master interface 3.Front port : 128-bit AXI slave interface |
||||
